LW20/HA high-accuracy IP67 LiDAR sensors

High accuracy, ultra compact LiDAR in an IP67 enclosure

$389.00 excl. Taxes

Available on backorder

Available on backorder

Applications

Simultaneous Localization and Mapping, Position hold, Vehicle & pedestrian counting, Inventory management, Profiling vehicle shapes, Robotics
View product guide
Compact rectangular LW20 sensor with a silver housing and two large purple-tinted lenses on a light gray background.
LW20/HA high-accuracy IP67 LiDAR sensors - Image 2
Compact rectangular LW20 sensor with a silver housing and two purple-tinted lenses, shown with dimensions of 30 mm wide by 20 mm high.
LW20/HA high-accuracy IP67 LiDAR sensors - Image 4
LW20/HA high-accuracy IP67 LiDAR sensors - Image 5
LW20/HA high-accuracy IP67 LiDAR sensors - Image 6
LW20/C label
Silver rectangular LW20 sensor with an attached black cable ending in a multicolored wire connector, displayed on a light gray background.
New standard in accuracy

Setting new standards in accuracy for compact, 100m rangefinders with sub-1cm accuracy across the whole distance range.

Environmental protection

IP67 rated sensor
Dust and water-resistant for external mounting without needing additional protection

Dust penetration

First and last pulse detection
Resiliency in difficult environmental conditions, including dust, mist, fog, rain and snow

LW20/HA high-accuracy IP67 LiDAR sensors

Specifications

LW20/HA high-accuracy IP67 LiDAR sensors

Specifications

Range

0.2 to 100 m / 0.6 to 328 ft
Accuracy

Accuracy

Better than 1cm over 100m
Circular arrow icon with an orange lightning bolt at the center, representing power, energy efficiency, charging, or electrical cycling.

Update Rate

48 to 1 250 readings per second
Computer monitor icon with an orange heartbeat waveform across the screen and a dark blue stand on a white background.

Signal processing

First and last pulse available
Blue analog scale icon with a needle and two small feet, positioned beneath an orange semicircle on a white square background.

Weight

19.5 g / 0.69 oz
Blue and orange abstract icon featuring radiating lines and circular endpoints, resembling a sensor scan, signal burst, or connectivity graphic.

LiDAR type

Single beam
3D cube icon with arrows extending outward from the top and both bottom corners, shown in dark blue on a white background.

Size

30 mm x 20 mm x 43 mm / 1.2″ x 0.8″ x 1.7″
Two dark blue interlocking gear icons, one large and one small, on a white background.

Interfaces

Serial UART and I2C (3.3 V TTL, 5 V tolerant)
Play button icon with a dark blue triangle inside an orange outlined triangular shape, on a white square background.

Integration

PX4, ArduPilot, Arduino, Raspberry Pi and LW Studio
High accuracy
in water and dust?

The LW20/HA is enhanced with improvements in engineering and manufacturing in addition to that of the highly popular and globally respected LW20/C. This delivers the accuracy of up to a class-leading 1cm across the entire 100m distance range. The LW20/HA is provided in the same small yet robust and easy-to-use form factor that LW20/C users are used to, while unlocking new opportunities in the fields of UAV’s, robotics and safety.

Range

Measures 0.2 to 100 m / 0.6 to 328 ft, even in bright sunlight conditions. High accuracy across the whole range Maximum range achieved on targets with 70% reflectivity.

Accuracy

Accuracy < 1cm for 20°C to 30°C
< 2cm for 15°C to 20°C & 30°C to 35°C
< 5cm for 0°C to 15°C & 35°C to 50°C
< 10cm for -20°C to 0°C & 50°C to 60°C

In the box

LW20/HA microLiDAR® sensor (cable connected).

Applications

LW20/HA high-accuracy IP67 LiDAR sensors

Downloads

Download all comprehensive guidance and resources here.

Resource center

Accessories

Black mounting bracket with screw holes and a U-shaped clip, displayed on a light gray background.

Original price was: $9.95.Current price is: $6.99. excl. Taxes

ABS mounting bracket for LW20 (M2)(Final availability)

Add to cart
Black plastic mounting bracket with open clip-style support and screw holes, displayed on a light gray background.

Original price was: $9.95.Current price is: $6.99. excl. Taxes

ABS servo mounting bracket (BR DS919MG) for LW20 (Final availability)

Add to cart
Hardware mounting kit with two black hex keys, five screws, and a silver metal bracket arranged on a light gray background.

Original price was: $44.95.Current price is: $14.99. excl. Taxes

Aluminium stand kit for LW20 (Final availability)

Add to cart
ACC_BOB_08SUR-32S (Generic break out board for LW20 SF20 GRFseries)

$16.95 excl. Taxes

Generic break out board for LW20 / SF20 / GRF-series

Add to cart
USB interface adapter circuit board with a USB-C connector, featuring a black PCB labeled 'ACC_USB_Serial,' 'USB,' and 'CON3' on a light gray background.

$23.95 excl. Taxes

Generic USB adapter for LW20 / SF20 / GRF-series

Add to cart
Small black adapter board with two white ribbon-cable connectors labeled 'CON2,' mounted on a light gray background.

$2.95 excl. Taxes

Pixhawk adapter for LW20 / SF20 / GRF-series

Add to cart
