SF20/HA high-accuracy LiDAR altimeters

Class-leading accuracy and range in an ultralight package.

$359.00 excl. Taxes

Available on backorder

Available on backorder

Applications

Simultaneous Localization and Mapping, Position hold, Vehicle & pedestrian counting, Inventory management, Profiling vehicle shapes, Robotics
View product guide
Compact dual-lens SF20 LiDAR sensor with purple-tinted optical lenses in a black housing, shown against a light gray background.
SF20/HA high-accuracy LiDAR altimeters - Image 2
Compact black SF20 LiDAR sensor with dual iridescent lenses, shown on a gray background with dimensions labeled 30 mm wide and 20 mm high.
SF20/HA high-accuracy LiDAR altimeters - Image 4
SF20/HA high-accuracy LiDAR altimeters - Image 5
SF20/HA high-accuracy LiDAR altimeters - Image 6
SF20/HA high-accuracy LiDAR altimeters - Image 7
New standard in accuracy

Setting new standards in accuracy for ultralight, 100m rangefinders with sub-1cm accuracy across the whole distance range.

Reliable distance measurement

Sub-1cm precision across the entire 100m measuring range

Unlock additional capabilities

Servo driver onboard
With a servo driver onboard and dedicated mounting brackets, the SF20/HA allows for beam steering

SF20/HA high-accuracy LiDAR altimeters

Specifications

SF20/HA high-accuracy LiDAR altimeters

Specifications

Range

0.2 to 100 m / 0.6 to 328 ft
Accuracy

Accuracy

Better than 1cm over 100m
Circular arrow icon with an orange lightning bolt at the center, representing power, energy efficiency, charging, or electrical cycling.

Update Rate

48 to 1 250 readings per second
Computer monitor icon with an orange heartbeat waveform across the screen and a dark blue stand on a white background.

Signal processing

First and last pulse available
Blue analog scale icon with a needle and two small feet, positioned beneath an orange semicircle on a white square background.

Weight

7.5 g / 0.26 oz
Blue and orange abstract icon featuring radiating lines and circular endpoints, resembling a sensor scan, signal burst, or connectivity graphic.

LiDAR type

Static single beam
3D cube icon with arrows extending outward from the top and both bottom corners, shown in dark blue on a white background.

Size

30 mm x 20 mm x 32 mm / 1.2″ x 0.79″ x 1.3″
Two dark blue interlocking gear icons, one large and one small, on a white background.

Interfaces

USB, Serial UART and I2C (3.3 V TTL, 5 V tolerant)
Play button icon with a dark blue triangle inside an orange outlined triangular shape, on a white square background.

Integration

PX4, ArduPilot, Arduino, Raspberry Pi and LW Studio
Ultra-light, high accuracy distance sensing in a compact size.

The SF20/HA is meticulously designed and expertly manufactured to deliver up to 1cm accuracy across a 100m range – while weighing just 7.5g. This powerful combination unlocks new opportunities in the fields of UAV’s, robotics and safety.

Range

Measures 0.2 to 100 m / 0.6 to 328 ft, even in bright sunlight conditions. High accuracy across the whole range Maximum range achieved on targets with 70% reflectivity.

Accuracy

Accuracy < 1cm for 20°C to 30°C
< 2cm for 15°C to 20°C & 30°C to 35°C
< 5cm for 0°C to 15°C & 35°C to 50°C
< 10cm for -20°C to 0°C & 50°C to 60°C

In the box

SF20/HA microLiDAR® sensor, a serial & power cable, a nylon standoff screw and laser warning label.
