(4 customer reviews)

SF40/C (100 m)

Designed to give your machines spatial intelligence
End of Life, January 31 2025.

$799.00 excl. Taxes

5 in stock (can be backordered)

Applications

Detect and avoid, SLAM, BVLOS, Traffic management
All round detection

360° scanning microLiDAR®
The SF40/C is a 360° microLiDAR® sensor scanning in a horizontal plane around autonomous and robotic systems

Proactive notification

Alarm configuration
This scanning microLiDAR® offers 100 meter range and configurable alarms for obstacle detection

SLAM enabled

5.5 revolutions per second
The SF40/C’s 2D mapping capability can be visualised in LightWare Studio, and offers a maximum of 5.5. revolutions per second and 20 000 readings per second

SF40/C (100 m)

Specifications

SF40/C (100 m)

Specifications

Wavelength

905 nm

LiDAR type

Single beam, 360 degree spinning

Range

0.2 … 100 m / 0.6 … 328 ft

Update rate

20 000 readings per second and up to 5.5 revolutions per second

Signal processing

First pulse only

Weight

261 g / 9.21 oz

Size

70 mm (h) x 79 mm (dia) / 2.8″ x 3.1″

Interfaces

Serial UART (3.3 V TTL, 5 V tolerant)

Integration

ArduPilot, ROS, Arduino, Raspberry Pi and LW Studio
Need all-round detection?
Done and dusted.

Engineered to provide your machines with spatial intelligence, the SF40/C microLiDAR® offers comprehensive detection capabilities. With a 360° vision and a 100-meter range, the SF40/C scans in a horizontal plane around autonomous and robotic systems. Beyond detection and SLAM, it also provides proactive notifications through configurable alarms.

Range

Measures 0.2 to 100 m / 0.6 to 328 ft, even in bright sunlight conditions. Maximum range achieved on targets with 70% reflectivity.

Update
rate

Offers 5.5 revolutions per second or less, configurable to your unique requirements.

In the box

SF40/C microLiDAR® sensor (cable connected).

Applications

SF40/C (100 m)

Downloads

Download all comprehensive guidance and resources here.

Accessories

Sensing your world starts here:
our clients’ stories

LightWare microLiDAR® is proud to support our pioneering clients as they deliver innovative solutions in their respective industries. Here’s how they apply LiDAR and what they have to say about our microlidar® sensors.

Chairman-WuSpace_New
Chairman WüSpace
“We needed the best, smallest and most compact LiDAR out there. It was the only LiDAR that we found that was small enough and that had enough documentation that...”
Logo Flying For Wildlife3
Flying for WildLife
“We were completely blown away by both the SF30/D and the tablet app that was built for us in such a short period of time to really help us do what we do...”
Skyfish-New
Skyfish
“The LiDAR is fantastic. The form factor is great, it’s super light, super small, easy to mount doesn’t take up a lot of real estate. The level of customer service that...”

Customer reviews

4.5
Based on 4 reviews
5 star
50
50%
4 star
50
50%
3 star
0%
2 star
0%
1 star
0%
1-4 of 4 reviews
  1. RB

    Really impressed. Ordered and it arrives in 3 day … WOW! Now to hook it up and not smoke the product . Nice finishes compared to other Lidars. Looks good… will check back with performance and how easy the docs are to understandf. Well Done guys!!!

    (0) (0)
  2. ML

    I’ve ordered ~10 of these over the past two years. The only problem we’ve had was when a motor burnt out after we left it continually running for a long time (months) during development. Lightware was very helpful in replacing the product after we returned the burnt out device.

    (0) (0)
  3. MA

    Lightware was able to provide great service to our company for many times. The SF40/C is being purchased only by Lightware and for the reasons of being trust worthy with perfect quality also delivering on the promising time. Always grateful.

    (0) (0)
  4. PD

    We purchased a SF40/C and broke it before the first use due to our own fault. Lightware gave us great help The system is working great; and we already bought a second one ! Thank you Lightware team !!!

    (0) (0)
